| EAN | 8717775930037 |
|---|
| Connection |
Bottom connection |
|---|---|
| Installation depth |
63 mm |
| Size |
100 x 100 mm |
| Anti-slip value grid |
R10 |
| Tax Schedule |
3 kN (300 kg) |
| Load class grating EN 1253 |
K3 (300 kg) |
| Particulars |
Outside of floor drain fitted with SBR rubber ring for optimum sealing in concrete |
| Capacity (max.) |
0.50 l/s |
| Connection diameter |
ø 50 mm |
| Bucket |
No |
| Material |
Stainless steel 304 |
| Material odor trap |
PPC plastic |
| Material grid |
Stainless steel AISI 304 (EN 1.4301) |
| Material/type of ring chamber |
NBR rubber o-ring |
| Floor drain material |
Stainless steel AISI 304 (EN 1.4301) |
| Material thickness grid |
2.0mm |
| Surface treatment grid |
High gloss |
| Placement advice |
Yes |
| Product protection |
Mortar lid |
| Scent lock |
37 mm |
| Removable odour trap |
Yes |
| Slot width grid |
6.0 mm |
| Application |
Bathroom |
| Locked grid |
No |
| Glueable |
No |
| Adjustability |
Not adjustable in height |
| Shape grid |
Square, slotted holes |
| Dirt collection basket |
No |
